Self-Adhesive Strip Packaging

Card Self-Adhesive Strip Packaging

Self-Adhesive Strip Packaging - CHANFER card packaging solution

Reclosable self-adhesive strip bags — ideal for premium card products requiring re-sealability. Each bag features a peel-and-seal strip for repeated opening and closing, protecting card quality during retail display and consumer use.

Self-adhesive strip packaging creates reclosable bags with a peel-and-seal strip that allows repeated opening and closing. This method is ideal for premium card products requiring re-sealability — collectors can open and close the package multiple times while keeping their cards protected.

CHANFER's self-adhesive strip bagging machine supports three sealing methods: self-adhesive strip (reclosable), hot-cut (permanent seal), and hot-press (permanent seal with premium finish). This versatility allows manufacturers to use the same machine for different product lines — from reclosable collector sets to permanently sealed retail packs.

The machine features automatic correction technology to reduce packaging loss, anti-air-bag detection (no material, no film wasted), and freely adjustable bag width for multi-specification products. One-click reset and bidirectional position control make changeover between product sizes quick and intuitive.

For premium card products, the self-adhesive strip method provides a retail-ready presentation that communicates quality. The clear film allows full product visibility while the reclosable strip adds functionality that consumers appreciate. Production speeds of 30-90 packs per minute balance quality and throughput for mid-volume premium production.

The complete line integrates with friction feeders for automatic card counting, cartoning machines for secondary packaging, and palletizing robots for end-of-line automation. Point memory functionality enables accurate counting and batch packing for limited edition sets.

Technical Specifications

Speed
30–90 packs/min
Film Roll Dia.
Φ450mm
Film Width
350mm (folding film)
Inner Dia.
76mm
Voltage
AC380V 50Hz 11.4KW

Key Features

  • Three sealing methods: self-adhesive, hot-cut, or hot-press
  • Automatic correction to reduce packaging loss
  • Anti-air-bag detection — no material, no film wasted
  • Freely adjustable bag width for multi-spec products
  • One-click reset and bidirectional position control
  • Point memory for accurate counting and batch packing

Why Choose Self-Adhesive Strip Packaging?

  • Reclosable functionality — peel-and-seal strip for repeated opening
  • Three sealing methods in one machine — self-adhesive, hot-cut, hot-press
  • Premium retail presentation — clear film with quality strip closure
  • Anti-waste technology — no material, no film wasted
  • Flexible bag width — adjustable for multi-spec products
  • Point memory for accurate counting and batch packing

Ideal For

Premium card collector setsRe-sealable card storage bagsRetail-display card packsLimited edition card bundles

Watch in Action

Complete Production Line

Self-Adhesive Strip Packaging - Full Production Line

Production Line Components

1. Friction Feeder2. Bagging Machine3. Sealing & Cutting Shrinkage Machine4. Unpacking Machine5. H-Type Carton Sealer6. Collaborative Palletizing Robot

Packaging Process

1Friction Feeder Count
2Bagging Machine
3Manual Cartoning
4Sealing & Cutting Shrinkage
5Case Packing
6H-Type Carton Sealer
7Collaborative Palletizing Robot

Self-Adhesive Strip Packaging FAQ

Self-adhesive strip packaging creates reclosable bags with a peel-and-seal strip. The bag can be opened and closed multiple times, making it ideal for premium card products where consumers want to access their cards while keeping them protected. Production speed: 30-90 packs/min.
